智能助行机器人设计-行走机构与机械系统设计(附SolidWorks三维图)(任务书,开题报告,外文翻译,论文说明书9400字,SolidWorks三维图)
摘 要
通过对机器人的研究开发,研制出一款帮助行走不便的老人和弱视的残疾人的日常辅助行走机器人。但目前国内外的助行机器人的缺点较多:自身重量较大、提供的承载能力不足、不能适应复杂的环境和地面和所需传感器价值的昂贵等 。本次论文便是尽可能的解决以上问题,并完成机器人的机械设计、运动学分析等方面。
根据分析出的机器人的研制目标,最终确定出机器人的总体设计方案。通过机器人的设计特点和相关元件着手,确定电机以链传动带动后轮差动方式驱动的机器人行走,以丝杠螺母的方式辅助用户完成站立坐下等动作,再以蜗轮蜗杆完成自锁。

关键词:机器人,机构设计,助行,智能。

The walker robot design - walking mechanism and mechanical system design
Abstract
Through the research and development of the robot ,walking robot is developed to help the old man walking and amblyopia of disabled People's Daily assisted . But a walker robot at home and abroad has more disadvantages: its weight is bigger, the bearing capacity of less than, can not adapt to the complex environment and the ground, and the required expensive sensor value, etc. This thesis is as much as possible to solve the above problems, and complete the robot mechanical design and kinematics analysis, etc.
According to the analysis of the robot's development goals, and ultimately determine the overall design of the robot. Through the design characteristics of the robot and related components, determine the motor to drive chain drives the rear wheel differential way of walking robot, assist the user in the form of lead screw nut finish the action, such as stand up sit down again to complete self-locking worm gear and worm.

Keywords: robot, mechanism design, walker,smart.
