车辆驱动桥NVH开发工作流程及性能指标体系(中文6400字,英文4500字)
摘要:
在全轮驱动或后轮驱动车辆的传动系统中,驱动桥是主要的传动部件。从噪声和振动的角度来看,驱动桥不仅是发动机激励的传递路径,而且由于其内齿轮组的啮合运动而成为激励源。驱动桥作为一种精密装配,其设计参数和制造工艺对车辆的NVH性能有很大的影响。本文提出了一种车辆驱动桥NVH开发的工作流和级联目标系统。为了有效地从根本上控制与驱动桥有关的NVH性能,本文首先研究了零部件的各种运动学和结构特性,得出了关键的设计参数。为了获得这些参数的可接受范围,在分析总结前人研究成果的基础上,进行了大量的CAE仿真工作,包括有限元分析、多体仿真和专业齿轮设计软件仿真。在装配了具有优化参数的原型轴后,在试验台和车辆上进行了实际的NVH试验,以验证设计的正确性。为了满足批量生产的需要,基于NVH性能与检测参数的相关性分析,提出了一种在线检测程序。最后,总结了生产流程和检验标准,为车轴工程师在生产开发的早期阶段提供参考。
Proposed Workflow and Performance Targets System for NVH Development of Vehicle Drive Axle
Abstract
n the driveline system of all-wheel drive or rear-wheel drive vehicle, drive axle is a major transmission component.
